Description
The JA-110i indicator signals section setting or PG output activation (1-32) by a red LED . It is connected to the control panel via the bus.
JA-110I Bus section/output PG activation indicator
The indicator is non-addressable (not occuping an alarm system position).
Specifications
| Power | 12 V bus (9 … 15 V) |
|---|---|
| Current consumption in standby (LED on / off) | 6 mA / 3 mA |
| Current consumption for choice of cable | 6 mA |
| Dimensions | 62 x 36 x 27 mm |
| Classification | grade 2 according to EN 50131-1, EN 50131-3 |
| Environment according to | EN 50131-1. general indoor |
| Operating temperature range | -10 to + 40 ° C |
| Complies with | EN 50130-4, EN 55022 |
