UNIVIEW NVR302-08S 8Ch 2 Sata HDD 1U 4K

$0

Out of stock

SKU NVR302-08S-P8 Category
SKU NVR302-08S-P8 Category

$0

Out of stock

Description

8/16 Channel 2 HDDs NVR

• Support Ultra265/H.265/H.264 video formats
• 8/16-channel input
• Plug & Play with 8/16 independent PoE network interfaces
• Third-party IP cameras supported with ONVIF conformance: Profile S, Profile G, Profile T
• Support HDMI and VGA simultaneous output
• Up to 8 Megapixels resolution recording
• 2 SATA HDDs, up to 10TB for each HDD
• ANR technology to enhance the storage reliability when the network is disconnected
• Support cloud upgrade

Model NVR302-08S-P8 NVR302-16S-P8 NVR302-16S-P16
Video/Audio Input
IP Video Input 8-ch 16-ch 16-ch
Two-way Audio Input 1-ch, RCA
Network
Incoming Bandwidth 160Mbps
Outgoing Bandwidth 96Mbps 96Mbps 96Mbps
Remote Users 128
Protocols P2P, UPnP, NTP, DHCP, PPPoE
Video/Audio Output
HDMI/VGA Output VGA:
1024X768@60, 1280X720@60, 1280X1024@60, 1920X1080@50, 1920X1080@60
HDMI:
4k (3840×2160@30), 4k (3840×2160@60), 1024X768@60, 1280X720@60, 1280X1024@60, 1920X1080@50, 1920X1080@60
Recording Resolution 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
Audio Output 1-ch, RCA
Synchronous Playback 8-ch 16-ch 16-ch
Corridor Mode Screen 3/4/5/7/9 3/4/5/7/9/10/12/16 3/4/5/7/9/10/12/16
Decoding
Decoding format Ultra265/H.265/H.264
Live view/Playback 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
Capability 1 x 4K@30, 2 x 4MP@30, 3 x 3MP@25, 4 x 1080P@30, 8 x 720P@30 1 x 4K@30, 2 x 4MP@30, 3 x 3MP@25, 4 x 1080P@30, 8 x 720P@30,16 x D1 1 x 4K@30, 2 x 4MP@30, 3 x 3MP@25, 4 x 1080P@30, 8 x 720P@30,16 x D1
Hard Disk
SATA 2 SATA interfaces
Capacity up to 10TB for each disk
External Interface
Network Interface 1 RJ-45 10M/100M/1000M self-adaptive Ethernet Interface
USB Interface Front panel: 1 x USB2.0, Rear panel: 1 x USB2.0
Alarm In 4-ch
Alarm Out 1-ch
PoE
Interface 8 independent 100Mbps PoE network interfaces 16 independent 100Mbps PoE network interfaces
Max Power Max 30W for single port
Max 130W in total (16.25W for each)
Max 30W for single port
Max 130W in total (16.25W for each)
Max 30W for single port
Max 240W in total (15W for each)
Supported Standard IEEE 802.3af/at
General
Power Supply 220V AC
Power Consumption: ≤9 W (without HDD)
Working Environment -10°C~+ 55°C (+14°F~+131°F), Humidity ≤ 90% RH (non-condensing)
Dimensions (W×D×H) 380mm ×315mm × 53mm (15.0″ × 12.4″ ×2.1″)
Weight (without HDD) ≤2.4kg (5.29lb)

Datasheet of NVR302-S-P

Network Video Recorders Quick Guide-V1.04

Network Video Recorders User Manual
